DACAS-Digital Analysis Core Alignment Systems
German CNC technique and integrated fiber-adjust frame, which make performance much stable Fiber type identification function
V-groove precise alignment, high quality and low loss
Auto-splicing mode, using friendly design
DACAS-Digital Analysis Core Alignment Systems
German CNC technique and integrated fiber-adjust frame, which make performance much stable Fiber type identification function
V-groove precise alignment, high quality and low loss
Auto-splicing mode, using friendly design
5" high resolution color LCD touch screen, 500X magnification, visible clearly with bare eyes Packed with detachable 5200mAh battery, more than 250 times of splicing and heating Dust-proof, water-proof, high-temperature resistance, adapting to various altitude and harsh environment 3 high-power white LEDs and illuminated keypads simplifies your work at night
Detachable multifunction fixture, suitable for various fiber type
Built -in Japanese components and Korean chipset
Optical imaging system ranks No. 1 in the world
Fusion spiicer*1 Fiber cleaver*1 Battery* 1
Power adapter* 1 AC power line*1 Back-up electrode*1 Cooling tray*1 Carrying case*1 Carrying strap* 1 User manual*1 Splicing test report*1 Fiber stripper*1 Drop cable stripper* 1 Alcohol bottle*1
| Equipment Parameters | |
| Model | |
| Dimension | 130W*160L*140H (including rubber bumper) |
| Weight | 2215G (with battery) / 1835G (without battery) |
| Number of Fiber | Single |
| Applicable Fibers | SM(ITU-T G.652& G.657)/MM(ITU-T G.651)/DS(ITU-T G.653)/NZDS(ITU-T G.655) |
| Compatible Fiber/Cable | 0.25 - 3.0mm/lndoor Cable |
| Cleaved Length | Diameter: 0.125 -1 mm/Cleave Length: 8-16mm |
| Cladding Diameter | 80 - 150 pm |
| Splicing Mode | Pre-set 41 splicing modes, max 100 modes |
| Heating Mode | Pre-set 5 heating modes (20/30/40/50/60mm), max 100 modes |
| Typical Splice Loss | SM: 0.02dB / MM: 0.01dB/ DS: 0.04dB / NZDS: 0.04 dB/ G.657: 0.02dB (ITU-T Standard) |
| Return Loss | >60dB |
| Lighting | 3 White LEDs |
| Splicing Time | Quick mode: 6s |
| Estimated Splice Loss | Available |
| Heating Sleeve Length | 20 - 60 mm |
| Heating Time | Quick heating time: 13s, typical heating time: 30s |
| Results Storage | 20000 latest records & 200 images |
| Tension Test | 1.96-2.25N |
| Operating Condition | Operating Altitude: 0 - 5000m above sea level, 0 - 95% relative humidity, -10~ 50°C Max Wind 15m/s |
| Storage Condition | 0 ~ 95% relative humidity, -40 ~ 80°C |
| Display | 90° bi-directional view, 5.0" Color High Resolution Display |
| Fiber View & Magnification | X, Y, XY, X/Y: 500X Magnification |
| Power Supply | AC Input 100 - 240V, DC Input 12- 15V |
| No. of Splice/Heating with Battery | 5200mAh Battery Capacity, Typical 250 times (Splice + Heat) |
| Operating Methods | Button/Touch Screen |
| Automatic Calibration | Automatic arc calibration by air pressure and temperature |
| Electrode Life | 5000 arcs |
| Terminal | Mini USB 2.0 |
